Features:
1. Adopting instant light metal halide UV lamp so as to shorten exposure time – save electricity and prolong lamp life.
2. No smoke odor and no air pollution.
3. The chest of the machine is sealed and the operator does not have to worry about being harmed by UV light.
4. Rubber blanket is made by durable and good elasticity material to ensure fast vacuum effect.
5. Vacuum pressure is adjustable to meet different kinds of stencil material.
6. The machine uses non-oil vacuum pump to eliminate the trouble of changing oil and it is quite during operation.
7. All the components are located inside the chest of the machine – save floor space and easy for maintenance.
8. The machine has 60 channel memories for exposure control with UV light integrator to assure stable light density.
|
|
VPF32HS-1 |
VPF32HS-2 |
VPF32HS-3 |
|
1300*1170*1210mm |
1510*1370*1210mm |
1720*1570*1210mm |
|
Effective area |
700*900mm |
1000*1200mm |
1200*1400mm |
|
Light Source |
3KW instant light (standard) 6KW/4KW(optional) |
||
|
Vacuum Pump |
Straight joined pump |
||
|
Control Type |
60 sets computer memorized programed |
||
|
Power Source |
220V 1₡ 3KW/22A 6KW/45A 4KW/30A |
||
|
Net Weight |
180 KGS |
250 KGS |
290 KGS |
| Colour(s) | No |
|---|---|
| Packing / Size | 1 |
| Unit of Measurement | UNIT |
| Manufacturer | No |
| Country of Origin | Taiwan |
